PCB  Wire Protection  Terminal Block Connector AK167R-5.0

PCB Wire Protection Terminal Block Connector AK167R-5.0

  • Specifications
  • 1 Model Number:AK167R-5.0
  • 2 Pitch:5.0mm
  • 3 Rated: 250V,16A
  • 4 Type: Wire Protection  Terminal Block Connector
  • 5 Color: Green
  • 6 Wire Range:22-14AWG(2.5MM2)
  • 7 Pole:2p 3p to any pole
  • 8 Brand: SZOMK
  • 9 Sample Available

Quick Details:

1 Place of Origin: Zhejiang, China (Mainland)
2 Packaging Details:Box length:260mm ,Width:200mm Depth:100mm .1000pcs/box
3 Delivery Detail:normally 3-5 days after payment
4 Top quality products with certification of CE,UL,ROHS
5 Prompt reponse for your inquiry


Characterization

PCB terminal block is mainly characterized by the monomer and the  circuit  board  soldering  and wiring easy, and reliable screw  connection. The pitch is 3.5, 3.81, 5.0, 5.08,  and so on. The  terminal  blocks  can  be  combined  with 3P and 2P. The products without stitching are also available. The wiring directions are front, side, slope and other different styles.
